 Constant Current Power Driver Options

Standard Shape:

150/200W | 75W / 95W | 35W/ 50W | 35W UL | 50W UL | 75W UL | 100W UL | 120W UL | 150W UL | 200W UL | 300W | Multi Channel

Thin Shape:

 12W Slim Shape | 24W Slim Shape | 36W Slim Shape | 50W Slim Shape

Round Shape:

 25W | 40W

 Series Descriptions Series Data Sheets Type Input (Vac) (W) (V) Output  (A) Current Dim Channels (CNR) UL CE
150W/200W

(X represent W，V，M，T）

W：Current and Voltage
adjustable；

V：Current adjustable

M：0-10V & PWM dimming

T：Timing Contro		 JALS-150X012 CC 100 ~ 277 150 12 12.5 Y 1 N √
JALS-150X015 CC 100 ~ 277 150 15 10 Y 1 N √
JALS-150X020 CC 100 ~ 277 150 20 7.5 Y 1 N √
JALS-150X024 CC 100 ~ 277 150 24 6.2 Y 1 N √
JALS-150X030 CC 100 ~ 277 150 30 5 Y 1 N √
JALS-150X036 CC 100 ~ 277 150 36 4.2 Y 1 N √
JALS-150X042 CC 100 ~ 277 150 42 3.6 Y 1 N √
JALS-150X048 CC 100 ~ 277 150 48 3.2 Y 1 N √
JALS-150X054 CC 100 ~ 277 150 54 2.8 Y 1 N √
JALS-200X012 CC 100 ~ 277 200 12 12.5 Y 1 N √
JALS-200X015 CC 100 ~ 277 200 15 12 Y 1 N √
JALS-200X020 CC 100 ~ 277 200 20 10 Y 1 N √
JALS-200X024 CC 100 ~ 277 200 24 8.3 Y 1 N √
JALS-200X030 CC 100 ~ 277 200 30 6.6 Y 1 N √
JALS-200X036 CC 100 ~ 277 200 36 5.5 Y 1 N √
JALS-200X042 CC 100 ~ 277 200 42 4.8 Y 1 N √
JALS-200X048 CC 100 ~ 277 200 48 4.2 Y 1 N √
JALS-200X054 CC 100 ~ 277 200 54 3.7 Y 1 Y √
TOP DRIVERS MENU | REQUEST DATA SHEET
75W/96W

X represent W，V，M，T）

W：Current
and Voltage adjustable

V：Current adjustable

M：0-10V & PWM dimming

T：Timing Control		 JALS-C-075X012 CC 100 ~ 277 75 12 5 Y 1 Y √
JALS-C-075X015 CC 100 ~ 277 75 15 4 Y 1 Y √
JALS-C-075X020 CC 100 ~ 277 75 20 3.75 Y 1 Y √
JALS-C-075X024 CC 100 ~ 277 75 24 3.15 Y 1 Y √
JALS-C-075X030 CC 100 ~ 277 75 30 2.5 Y 1 Y √
JALS-C-075X036 CC 100 ~ 277 75 36 2.1 Y 1 Y √
JALS-C-075X042 CC 100 ~ 277 75 42 1.8 Y 1 N √
JALS-C-075X048 CC 100 ~ 277 75 48 1.6 Y 1 N √
JALS-C-075X054 CC 100 ~ 277 75 54 1.4 Y 1 N √
JALS-C-096X012 CC 100 ~ 277 96 12 6 Y 1 N √
JALS-C-096X015 CC 100 ~ 277 96 15 5 Y 1 N √
JALS-C-096X020 CC 100 ~ 277 96 20 4.8 Y 1 N √
JALS-C-096X024 CC 100 ~ 277 96 24 4 Y 1 N √
JALS-C-096X030 CC 100 ~ 277 96 30 3.2 Y 1 N √
JALS-C-096X036 CC 100 ~ 277 96 36 2.65 Y 1 N √
JALS-C-096X042 CC 100 ~ 277 96 42 2.3 Y 1 N √
JALS-C-096X048 CC 100 ~ 277 96 48 2 Y 1 N √
JALS-C-096X054 CC 100 ~ 277 96 54 1.8 Y 1 N √
TOP DRIVERS MENU | REQUEST DATA SHEET
35W/50W

(X represent W，V，M，T）

W：Current
and Voltage adjustable

V：Current adjustable

M：0-10V & PWM dimming

T：Timing Control		 JALS-C-035X012 CC 100 ~ 277 35 12 2.9 Y 1 Y √
JALS-C-035X015 CC 100 ~ 277 35 15 2.3 Y 1 Y √
JALS-C-035X020 CC 100 ~ 277 35 20 1.75 Y 1 Y √
JALS-C-035X024 CC 100 ~ 277 35 24 1.4 Y 1 Y √
JALS-C-035X030 CC 100 ~ 277 35 30 1.15 Y 1 Y √
JALS-C-035X036 CC 100 ~ 277 35 36 1.05 Y 1 Y √
JALS-C-035X042 CC 100 ~ 277 35 42 0.83 Y 1 N √
JALS-C-035X048 CC 100 ~ 277 35 48 0.7 Y 1 N √
JALS-C-35X054 CC 100 ~ 277 35 54 0.6 Y 1 N √
JALS-050X012 CC 100 ~ 277 50 12 4.2 Y 1 Y √
JALS-050X015 CC 100 ~ 277 50 15 3.3 Y 1 Y √
JALS-050X020 CC 100 ~ 277 50 20 2.5 Y 1 Y √
JALS-050X024 CC 100 ~ 277 50 24 2 Y 1 Y √
JALS-050X030 CC 100 ~ 277 50 30 1.6 Y 1 Y √
JALS-050X036 CC 100 ~ 277 50 36 1.4 Y 1 Y √
JALS-050X042 CC 100 ~ 277 50 42 1.2 Y 1 N √
JALS-050X048 CC 100 ~ 277 50 48 1.05 Y 1 N √
JALS-050X054 CC 100 ~ 277 50 54 0.9 Y 1 N √
TOP DRIVERS MENU | REQUEST DATA SHEET
35W UL JAEU-C-035S290ST/DT CC 100 ~ 277 35 12 2.9 0~10V 1 Y √
JAEU-C-035S245ST/DT CC 100 ~ 277 35 15 2.45 0~10V 1 Y √
JAEU-C-035S210ST/DT CC 100 ~ 277 35 18 2.1 0~10V 1 Y √
JAEU-C-035S175ST/DT CC 100 ~ 277 35 20 1.75 0~10V 1 Y √
JAEU-C-035S140ST/DT CC 100 ~ 277 35 24 1.4 0~10V 1 Y √
JAEU-C-035S105ST/DT CC 100 ~ 277 35 33 1.05 0~10V 1 Y √
JAEU-C-035S070ST/DT CC 100 ~ 277 35 50 0.7 0~10V 1 N √
JAEU-C-035S045ST/DT CC 100 ~ 277 35 78 0.45 0~10V 1 N √
JAEU-C-035S035ST/DT CC 100 ~ 277 35 100 0.35 0~10V 1 N √
TOP DRIVERS MENU | REQUEST DATA SHEET
40W UL JAEU-C-040S105DS CC 100 ~ 277 40 100 0.48 0~10V 1 N √
TOP DRIVERS MENU | REQUEST DATA SHEET
50W UL JAEU-C-050S035ST/DT CC 100 ~ 277 50 142 0.35 0~10V 1 N √
JAEU-C-050S045ST/DT CC 100 ~ 277 50 110 0.45 0~10V 1 N √
JAEU-C-050S070ST/DT CC 100 ~ 277 50 72 0.7 0~10V 1 N √
JAEU-C-050S110ST/DT CC 100 ~ 277 50 48 1.1 0~10V 1 N √
JAEU-C-050S140ST/DT CC 100 ~ 277 50 36 1.4 0~10V 1 Y √
JAEU-C-050S175ST/DT CC 100 ~ 277 50 29 1.75 0~10V 1 Y √
JAEU-C-050S210ST/DT CC 100 ~ 277 50 24 2.1 0~10V 1 Y √
JAEU-C-050S280ST/DT CC 100 ~ 277 50 18 2.8 0~10V 1 Y √
JAEU-C-050S333ST/DT CC 100 ~ 277 50 15 3.33 0~10V 1 N √
JAEU-C-050S420ST/DT CC 100 ~ 277 50 12 4.2 0~10V 1 N √
TOP DRIVERS MENU | REQUEST DATA SHEET
75W UL JAEU-C-075S500ST CC 100 ~ 277 75 15 5A N 1 Y √
JAEU-C-075S375ST CC 100 ~ 277 75 20 3.75A N 1 N √
JAEU-C-075S280ST CC 100 ~ 277 75 27 2.8A N 1 N √
JAEU-C-075S210ST CC 100 ~ 277 75 36 2.1A N 1 N √
JAEU-C-075S140ST CC 100 ~ 277 75 50 1.4A N 1 N √
JAEU-C-075S105ST CC 100 ~ 277 75 72 1.05A N 1 N √
JAEU-C-075S070ST CC 100 ~ 277 75 108 0.7A N 1 N √
JAEU-C-075S045ST CC 100 ~ 277 75 166 0.45A N 1 N √
JAEU-C-075S035ST CC 100 ~ 277 75 214 0.35A N 1 N √
TOP DRIVERS MENU | REQUEST DATA SHEET
100W UL JAEU-C-100S420ST CC 100 ~ 277 100 24 4.2A N 1 N √
JAEU-C-100S357ST CC 100 ~ 277 100 28 3.57 A N 1 N √
JAEU-C-100S315ST CC 100 ~ 277 100 32 3.15A N 1 N √
JAEU-C-100S280ST CC 100 ~ 277 100 36 2.8A N 1 N √
JAEU-C-100S245ST CC 100 ~ 277 100 41 2.45A N 1 N √
JAEU-C-100S210ST CC 100 ~ 277 100 48 2.1A N 1 N √
JAEU-C-100S175ST CC 100 ~ 277 100 50 1.75A N 1 N √
JAEU-C-100S140ST CC 100 ~ 277 100 71 1.4A N 1 N √
JAEU-C-100S105ST CC 100 ~ 277 100 95 1.05A N 1 N √
JAEU-C-100S070ST CC 100 ~ 277 100 143 0.7A N 1 N √
JAEU-C-100S045ST CC 100 ~ 277 100 222 0.45A N 1 N √
JAEU-C-100S035ST CC 100 ~ 277 100 286 0.35A N 1 N √
TOP  DRIVER MENU | REQUEST DATA SHEET
120W UL JAEU-C-120S490ST CC 100 ~ 277 120 24 4.9 N 1 N √
JAEU-C-120S420ST CC 100 ~ 277 120 28 4.2 N 1 N √
JAEU-C-120S350ST CC 100 ~ 277 120 34 3.5 N 1 N √
JAEU-C-120S315ST CC 100 ~ 277 120 38 3.15 N 1 N √
JAEU-C-120S280ST CC 100 ~ 277 120 43 2.8 N 1 N √
JAEU-C-120S245ST CC 100 ~ 277 120 49 2.45 N 1 N √
JAEU-C-120S210ST CC 100 ~ 277 120 57 2.1 N 1 N √
JAEU-C-120S175ST CC 100 ~ 277 120 68 1.75 N 1 N √
JAEU-C-120S140ST CC 100 ~ 277 120 86 1.4 N 1 N √
JAEU-C-120S105ST CC 100 ~ 277 120 114 1.05 N 1 N √
JAEU-C-120S070ST CC 100 ~ 277 120 171 0.7 N 1 N √
JAEU-C-120S045ST CC 100 ~ 277 120 266 0.45 N 1 N √
JAEU-C-120S035ST CC 100 ~ 277 120 343 0.35 N 1 N √
TOP DRIVERS MENU | REQUEST DATA SHEET
150W UL JAEU-C-150S595ST CC 100 ~ 277 150 25 5.95 N 1 N √
JAEU-C-150S490ST CC 100 ~ 277 150 30 4.9 N 1 N √
JAEU-C-150S420ST CC 100 ~ 277 150 35 4.2 N 1 N √
JAEU-C-150S350ST CC 100 ~ 277 150 42 3.5 N 1 N √
JAEU-C-150S315ST CC 100 ~ 277 150 47 3.15 N 1 N √
JAEU-C-150S280ST CC 100 ~ 277 150 50 2.8 N 1 N √
JAEU-C-150S245ST CC 100 ~ 277 150 61 2.45 N 1 N √
JAEU-C-150S210ST CC 100 ~ 277 150 71 2.1 N 1 N √
JAEU-C-150S175ST CC 100 ~ 277 150 85 1.75 N 1 N √
JAEU-C-150S140ST CC 100 ~ 277 150 107 1.4 N 1 N √
JAEU-C-150S105ST CC 100 ~ 277 150 142 1.05 N 1 N √
JAEU-C-150S070ST CC 100 ~ 277 150 214 0.7 N 1 N √
JAEU-C-150S045ST CC 100 ~ 277 150 333 0.45 N 1 N √
JAEU-C-150S035ST CC 100 ~ 277 150 428 0.35 N 1 N √
TOP DRIVERS MENU | REQUEST DATA SHEET
200WUL JAEU-C-200S833ST CC 100 ~ 277 200 24 8.33 N 1 N √
JAEU-C-200S630ST CC 100 ~ 277 200 32 6.3 N 1 N √
JAEU-C-200S560ST CC 100 ~ 277 200 35 5.6 N 1 N √
JAEU-C-200S490ST CC 100 ~ 277 200 40 4.9 N 1 N √
JAEU-C-200S420ST CC 100 ~ 277 200 47 4.2 N 1 N √
JAEU-C-200S350ST CC 100 ~ 277 200 50 3.5 N 1 N √
JAEU-C-200S315ST CC 100 ~ 277 200 63 3.15 N 1 N √
JAEU-C-200S280ST CC 100 ~ 277 200 71 2.8 N 1 N √
JAEU-C-200S245ST CC 100 ~ 277 200 81 2.45 N 1 N √
JAEU-C-200S210ST CC 100 ~ 277 200 95 2.1 N 1 N √
JAEU-C-200S175ST CC 100 ~ 277 200 114 1.75 N 1 N √
JAEU-C-200S140ST CC 100 ~ 277 200 142 1.4 N 1 N √
JAEU-C-200S105ST CC 100 ~ 277 200 190 1.05 N 1 N √
JAEU-C-200S070ST CC 100 ~ 277 200 285 0.7 N 1 N √
JAEU-C-200S045ST CC 100 ~ 277 200 445 0.45 N 1 N √
TOP DRIVERS MENU | REQUEST DATA SHEET
300W JAMS-T7000IC42.0-300B CC 101 ~ 277 300 22-36 0.42 N 1 N √
TOP DRIVERS MENU | REQUEST DATA SHEET
Multiple Channels  JAMS-T0700IC48.0-100Y3 CC 100 ~ 277 100 48 0.65A N 3 N √ √
JAMS-T0900IC42.0-150C3 CC 100 ~ 277 150 42 0.9A N 3 N √
JAMS-T0650IC42.0-150Y4 CC 100 ~ 277 150 48 0.65A N 4 N √
JAMS-P-TA700IC52V0-150R4 CC 100 ~ 277 150 52 0.7A N 4 N √ √
JAMS-P-TA350IC50V0-150S8 CC 100 ~ 277 150 50 0.35A N 8 N √

TOP DRIVERS MENU | REQUEST DATA SHEET
12W Slim Shape JAMS-P-ZA300IC40V0-012W CC 100 ~ 277 12 40 0.3A N 1 N √
JAMS-P-ZA350IC34V0-012W CC 12 34 0.35A N 1 Y √
JAMS-P-ZA500IC24V0-012W CC 12 24 0.5A N 1 Y √
JAMS-P-ZA700IC17V0-012W CC 12 17 0.7A N 1 Y √
JAMS-P-Z1A05IC12V0-012W CC 12 12 1.05A N 1 Y √
JAMS-P-Z1A40IC9V00-012W CC 12 9 1.4A N 1 Y √
TOP DRIVERS MENU | REQUEST DATA SHEET
24W Slim Shape JAMS-P-ZA350IC68V0-024W CC 100 ~ 277 24 68 0.35A N 1 N √
JAMS-P-ZA500IC48V0-024W CC 24 48 0.5A N 1 N √
JAMS-P-ZA700IC34V0-024W CC 24 34 0.7A N 1 Y √
JAMS-P-Z1A05IC23V0-024W CC 24 23 1.05A N 1 Y √
JAMS-P-Z1A40IC17V0-024W CC 24 17 0-1.00A N 1 Y √
JAMS-P-Z1A75IC14V0-024W CC 24 14 1.75A N 1 Y √
JAMS-P-Z2A10IC11V0-024W CC 24 11 2.1 N 1 Y √
TOP DRIVERS MENU | REQUEST DATA SHEET
36W Slim Shape JAMS-P-ZA350IC103V-036W CC 100 ~ 277 36 103 0.35A N 1 N √
JAMS-P-ZA500IC72V0-036W CC 36 72 0.5A N 1 N √
JAMS-P-ZA700IC51V0-036W CC 36 51 0.7A N 1 N √
JAMS-P-Z1A05IC34V0-036W CC 36 34 1.05A N 1 Y √
JAMS-P-Z1A40IC26V0-036W CC 36 26 1.4A N 1 Y √
JAMS-P-Z1A75IC21V0-036W CC 36 21 1.75A N 1 Y √
JAMS-P-Z2A10IC17V0-036W CC 36 17 2.1A N 1 Y √
TOP DRIVERS MENU | REQUEST DATA SHEET
50W Slim Shape JAMS-P-ZA300IC167V-050D CC 100 ~ 277 50 167 0-0.30A 0~10V 1 N √ √
JAMS-P-ZA350IC142V-050D CC 50 142 0-0.35A 0~10V 1 N √ √
JAMS-P-ZA450IC110V-050D CC 50 110 0-0.45A 0~10V 1 N √ √
JAMS-P-ZA620IC80V0-050D CC 50 80 0-0.62A 0~10V 1 N √ √
JAMS-P-ZA700IC72V0-050D CC 50 72 0-0.70A 0~10V 1 N √ √
JAMS-P-Z1A05IC48V0-050D CC 50 48 0-1.05A 0~10V 1 N √ √
JAMS-P-Z1A40IC36V0-050D CC 50 36 0-1.40A 0~10V 1 N √ √
JAMS-P-Z1A75IC28V0-050D CC 50 28 0-1.75A 0~10V 1 N √ √
JAMS-P-Z2A08IC24V0-050D CC 50 24 0-2.08A 0~10V 1 N √ √
JAMS-P-Z2A20IC22V0-050D CC 50 22 0-2.20A 0~10V 1 N √ √
JAMS-P-ZA300IC167V-050W CC 50 167 0.30A N 1 N √ √
JAMS-P-ZA350IC142V-050W CC 50 142 0.35A N 1 N √ √
JAMS-P-ZA450IC110V-050W CC 50 110 0.45A N 1 N √ √
JAMS-P-ZA620IC80V0-050W CC 50 80 0.62A N 1 N √ √
JAMS-P-ZA700IC72V0-050W CC 50 72 0.70A N 1 N √ √
JAMS-P-Z1A05IC48V0-050W CC 50 48 1.05A N 1 N √ √
JAMS-P-Z1A40IC36V0-050W CC 50 36 1.40A N 1 N √ √
JAMS-P-Z1A75IC28V0-050W CC 50 28 1.75A N 1 N √ √
JAMS-P-Z2A08IC24V0-050W CC 50 24 2.08A N 1 N √ √
JAMS-P-Z2A20IC22V0-050W CC 50 22 2.20A N 1 N √ √
TOP DRIVERS MENU | REQUEST DATA SHEET
25W Round Shape JAEU-C-025S208PS/DS CC 100 ~ 277（UL） 25 12 2.08 0~10V 1 Y  √ √
JAEU-C-025S175PS/DS CC 100 ~ 240（CE） 25 14 1.75 0~10V 1 Y  √ √
JAEU-C-025S140PS/DS CC 25 18 1.4 0~10V 1 Y  √ √
JAEU-C-025S105PS/DS CC 25 24 1.05 0~10V 1 Y  √ √
JAEU-C-025S070PS/DS CC 25 36 0.7 0~10V 1 Y  √ √
JAEU-C-025S062PS/DS CC 25 40 0.62 0~10V 1 N √ √
JAEU-C-025S045PS/DS CC 25 56 0.45 0~10V 1 N √ √
JAEU-C-025S035PS/DS CC 25 72 0.35 0~10V 1 N √ √
TOP DRIVERS MENU | REQUEST DATA SHEET
40W Round Shape JAEU-C-040S035PS/DS CC 100 ~ 277（UL） 40 114 0.35 0~10V 1 N √ √
JAEU-C-040S045PS/DS CC 100 ~ 240（CE） 40 89 0.45 0~10V 1 N √ √
JAEU-C-040S070PS/DS CC 40 54 0.7 0~10V 1 N √ √
JAEU-C-040S105PS/DS CC 40 36 1.05 0~10V 1 Y √ √
JAEU-C-040S128PS/DS CC 40 29 1.28 0~10V 1 Y √ √
JAEU-C-040S140PS/DS CC 40 25 1.4 0~10V 1 Y √ √
JAEU-C-040S166PS/DS CC 40 23 1.66 0~10V 1 Y √ √
JAEU-C-040S222PS/DS CC 40 16 2.22 0~10V 1 Y √ √
JAEU-C-040S333PS/DS CC   40 11 3.33 0~10V 1 Y √ √
TOP DRIVERS MENU | REQUEST DATA SHEET
