 Aluminum Electrolytic Capacitors: Thru-Hole
Data Sheets Type Op Temp Voltage Cap Range Tolerance Leak Features
JD5 Thru-Hole -40 ~ +85℃ 4 ~ 50VDC 0.1 ~ 220μF ± 20 % at 120Hz , 20℃ I≦0.01CV or 3(μA) whichever is greater 85℃,1000hrs, Low profile/Ultra Miniature, 5mm height - RoHS
JLG Thru-Hole -40 ~ +105℃
-25 ~ +105℃		 6.3 ~ 100VDC
160 ~ 450VDC		 560 ~ 82000μF
47 ~ 2200μF		 ± 20 % at 120Hz , 20℃ I=0.02CV,L=20m/m,I=0.03CV or 3mA , whichever is smaller. 105℃ 2000 hours:
Size Varies
JS7 Thru-Hole -40 ~ +105℃ 4 ~ 63VDC 0.1 ~ 470μF ± 20 % at 120Hz , 20℃ I=0.01CV or 3(μA) , whichever is greater. 105℃ 1000 hours , 7.0/9.0mm height
JSE Thru-Hole -40~+105℃
 40~+105℃
 25~+105℃		 6.3 ~ 100VDC
160 ~ 250VDC
350 ~ 450VDC		 0.47 ~ 15000μF
0.47 ~ 470μF
0.47 ~ 150μF		 ± 20 % at 120Hz , 20℃ I=0.01CV or 3(μA) ,whichever is greater. 105℃ 1000 hours:
Size Varies
JSH Thru-Hole -40~+105℃
25~+105℃		 6.3 ~ 100VDC
160 ~ 450VDC



 0.47 ~ 15000μF
0.47 ~ 470μF



 ± 20 % at 120Hz , 20℃ I=0.01CV or 3(μA) ,whichever is greater. 105℃ 2000 hours:
Size Varies
JSJ

Thru-Hole

 -40~+105℃ 6.3 ~ 100VDC 5.6 ~ 6800 μF ± 20 % at 120Hz , 20℃ I=0.01CV or 3(μA) ,whichever is greater. 105℃, 1000〜5000hrs Low Impedance and High ripple: Size Varies
JSP

Thru-Hole

 -40~+105℃
 25~+105℃		 160 ~ 400VDC 450VDC 3.3 ~ 330μF ± 20 % at 120Hz , 20℃ I=0.04CV + 100(μA) High temperature and long life at 105℃ for 8000 to 10000 hours: Size Varies
JST

Thru-Hole

 -40~+105℃



 6.3 ~ 105VDC 10 ~ 15000μF



 ± 20 % at 120Hz , 20℃ I=0.01CV or 3(μA) , whichever is greater 105℃ 4000~10000hrs Low Impedance and long Life
Size Varies
JSY

Thru-Hole

 -40~+105℃ 6.3 ~ 100VDC 2.2 ~ 15000μF ± 20 % at 120Hz , 20℃ I=0.01CV or 3(μA) , whichever is greater

Low Impedance, high permissible ripple current at high frequency & long life:
Size Varies
JSK

Thru-Hole

 -40~+85℃ 6.3 ~ 100VDC .1 ~ 2200μF ± 20 % at 120Hz , 20℃ I=0.01CV or 3(μA) , whichever is greater 85℃ 2000 hours
Size Varies
JLH

Thru-Hole

 -40~+85℃
 -25~+85℃		 6.3 ~ 100VDC
160 ~ 500VDC		 820 ~ 120000μF
47 ~ 2200μF
 		 ± 20 % at 120Hz , 20℃ I=0.02CV or 3(mA) , whichever is greater 85℃ 2000 hours
Size Varies
JLJ

Thru-Hole

 -40~+105℃
 -25~+105℃		 10 ~ 100VDC
160 ~ 450VDC		 560 ~ 68,000μF
56 ~ 2200μF
 		 ± 20 % at 120Hz , 20℃ I=0.02CV or 3(mA) , whichever is greater 105℃ 3000 hours, Wide temperature range for LF, Longer life than LG,
Snap-in terminal, High ripple current
JLF

Thru-Hole

 -40~+85℃
 -25~+85℃		 10 ~ 100VDC
160 ~ 450VDC		 820 ~ 56,000μF
56 ~ 2200μF
 		 ± 20 % at 120Hz , 20℃ I=0.02CV or 3(mA) , whichever is greater 85℃ 3000 hours , Longer life than LH, Snap-in terminal, High ripple current


Return to top





Aluminum Electrolytic Capacitors: Surface Mount
Links Type Op Temp Voltage Cap Range Tolerance Leak Features
JEV Surface Mt -40 ~ +105℃



 6.3 ~ 35VDC



 4.7 ~ 1500μF ± 20 % at 120Hz , 20℃ I≦0.01CV or 3μA whichever is greater 105℃ 2000 hours , Low profile vertical chip, Ultra low impedance:
JGV Surface Mt -40 ~ +85℃ 4 ~ 100VDC



 0.1 ~ 1500μF ± 20 % at 120Hz , 20℃ I≦0.01CV or 3(μA) , whichever is greater. 85℃ 2000 hours & Low profile vertical chip
Vertical Orientation
JZV Surface Mt  -40 ~ +105℃ 4 ~ 50VDC 1.0 ~ 1500μF ± 20 % at 120Hz , 20℃ I≦0.01CV or 3(μA) , whichever is greater. 105℃ 1000 hours , Wide temperature range, Low profile vertical chip,Low impedance
Vertical Orientation
JDV Surface Mt  -40 ~ +105℃ 6.3 ~ 50VDC 0.1 ~ 1500μF ± 20 % at 120Hz , 20℃ I≦0.01CV or 3(μA) , whichever is greater. 105℃ 2000 hours , Longer life than JSV, Low profile vertical chip




Return to top
Capacitors: Non-Lytic

Type Series Description Guide Spec Packaging Series Note
Ceramic Multilayer CC Standard Voltage 25VDC-100VDC
  CC High Voltage 250VDC-3000VDC

Type Series Description Guide Spec
Film PEC 105°C Standard PEN
  PECL 105°C Standard PEN
  PPC 125°C High Grade PPS
  PPCL 105°C High Grade PPS
  PPCX-16 Plastic Stacked - 16 VDC
  PPCX-25 Plastic Stacked - 25 VDC

Type Series Description Guide Spec
Special Polymer SPC Special Polymer

Type Series Description Guide Spec
Tantalum TC Standard
  TCF With Fuse - NEW
  TCLE Low ESR

Return to top
Ferrite Beads: Surface Mount

Type
Series
Description
Guide
Spec
Array MLB Multiple Lines


Type
Series
Description
Guide
Spec
Multilayer A General Loss
  B High Speed
  H MLB-201209
  L Low DC Resistance
  P Large Current
  R Ringing Prevention
  --- Type Number Explanation

Type Series Description Guide Spec
Wound SMB Wound Bead

Return to top





Inductor Chips: Surface Mount


Type
Series
Description
Guide
Spec
Inductors HFC High Frequency Wound
  THI High Frequency Thin Film
  HFI High Frequency Multilayer
  MLI Multilayer
  SMI Wound (sizes 322522 to 453232)
  SMSI Shielded - NEW!
  SPI Multiple Lines
  WCI Wound (sizes 453232 to 565050)

Return to top





Resistors: Surface Mount

Type Series Description Guide Spec
Resistors RC Thick Film
  RL Low Value Chip
  RM-RO Ceramic-Carbon--now in 2 Watt
  RT Thin Film
  RWN Metal Strip Technology
  SK Sample Kits
  SWM Wire Wound - Molded

Return to top





Resistors: Thru Hole


Type
Series
Description
Guide
Spec		 Packaging
Carbon JCC Carbon Composite - 1/4 - 1 Watt
Ceramic RT Ceramic Composite - 2 Watt

Type
Series
Description
Guide
Spec		 Packaging
Film w/ Jumpers J Zero Ohm Resistors
  JWP Jumper Wires Resistors

Type
Series
Description
Guide
Spec		 Packaging
Carbon Film F Flame Proof
  M Professional
  MF Professional & Flame-Proof
  S Standard

Type
Series
Description
Guide
Spec		 Packaging
Metal Film ERN General Purpose
  MNRN
  MOF Metal Oxide
  NRN Flame Proof
  RRN

Type
Series
Description
Guide
Spec		 Packaging
Metal Plate LMP Low Ohm Metal Plate Resistor

Type
Series
Description
Guide
Spec		 Packaging
TO Series TO 30-120 Watts

Type
Series
Description
Guide
Spec		 Packaging
Wirewound CB-CBN Cement - Axial Lead
  CBH-CBHN Cement - Clamp Mounting
  CBR-CBRN Cement - Vertical Lead
  CBZ-CBZN Cement - Radial Terminals
  KNP-NKN Flame Proof
  SR Silicon Power
  SRA Silicon Power Miniature

Return to top
